How to conduct automotive parts failure analysis?

Automotic parts failure analysis is an important part of the auto business because it helps find out why parts break, which improves product quality and makes cars safer. In this methodical process, failed parts are looked at, data is analyzed, and the causes of the failure are found. Manufacturers can make parts that are more reliable, lower the cost of warranties, and stop failures from happening in the future by doing thorough failure studies. This blog will talk about the main steps and methods used in car parts failure analysis, giving you an idea of how professionals in the field work. In this talk, we'll talk about how important it is to keep good records, do eye checks, test materials, and use advanced analysis tools to find out why parts fail. It is very important for automobile engineers, quality control experts, and anyone else who designs, builds, or fixes cars to understand these processes.

Gathering Information and Visual Inspection

Collecting Relevant Data

Getting all the important details about the failed part is the first step in car parts failure analysis. This includes the type, year, make, miles, and working conditions of the car at the time it broke down. Also, analysts should get any data from onboard monitoring systems as well as maintenance records and fix files. This thorough method helps put the failure in its proper context and may show trends or factors that led to it. When looking at car parts, it's important to write down where the part is in the car and if there are any obvious signs of damage, wear, or deformation. To get an exact picture of the part's state, photos and thorough notes should be taken.

Performing a Thorough Visual Inspection

It's important to carefully look over vehicle automotic parts to find clear signs that they are breaking. In this step, the surface of the part is checked for cracks, breaks, warping, or strange wear patterns. To find small flaws, analysts should use a variety of tools, like magnifying glasses or telescopes. It's important to look for signs of rust, wear, or bad assembly when checking out car parts. As part of the eye check, nearby parts that may have played a role in the failure should also be looked at. It is important to keep thorough notes and photos of all findings so that they can be analyzed further and reported.

Identifying Potential Failure Modes

Based on the first eye review and the data collected, researchers can start to figure out how the car parts in question might fail. Fatigue, pressure, wear, rust, and choosing the wrong material are all common ways that things break. Analysts can come up with ideas about what went wrong by looking at the part's function, its working surroundings, and the damage that has been seen. This step is very important for figuring out what to look into further and choosing the right testing methods. It's important to look at both design-related and manufacturing-related factors that could cause a car part to fail when studying it. This all-around method helps make sure that all possible reasons are looked into during the research.

Non-Destructive Testing and Analysis

Utilizing X-ray and CT Scanning

Automotive parts failure analysis uses X-rays and CT scans, which are strong non-destructive testing methods. Using these methods, scientists can look at the insides of parts without breaking them. Cracks, holes, or inclusions in car parts can be found with X-ray photography. As a next step, CT scans creates detailed 3D pictures of the part's internal shape. Choosing the right scanner settings for car parts depends on their material and shape. The resulting pictures can tell us a lot about potential flaws in the way the product was made, problems with the materials, or structure issues that may have led to the failure.

Performing Magnetic Particle Inspection

Non-destructive testing called magnetic particle inspection is often used on magnetized car automotic parts. Using this method, the part is magnetized and magnetic particles are put on its surface. The particles will gather in places where the magnetic field is interrupted by breaks or flaws in the material. Selecting the right magnetization method and particle type for magnetic particle checking on car parts depends on the shape and material qualities of the part. Many flaws, like cracks, splits, or spots, that are close to the surface or on the surface may not be obvious to the naked eye can be found using this method.

Applying Dye Penetrant Testing

In the study of how car parts fail, dye penetrant testing is another useful non-destructive way. In both metals and non-metals, this method works well for finding surface-breaking flaws. An colored or bright dye is put on the part's surface, which lets the dye seep into any cracks or other flaws. It is used to pull the penetrant out of the flaws and make them visible after the extra dye is removed. Always make sure the surface is clean and follow the right steps for applying and removing dye penetrant from car parts. Finding surface cracks, holes, or other breaks that may have caused the part to break is especially easy with this method.

Destructive Testing and Microscopic Analysis

Conducting Metallographic Examination

Metallographic study is an important damaging testing method for figuring out why car parts fail. To look at the substructure of the failed part using this method, a sample must be cut, mounted, and polished. Analysts can learn a lot about a material's qualities and possible failure reasons by looking at its grain structure, phase makeup, and any other unusual features. When metallographically inspecting car parts, it's important to pick samples that are representative of important parts of the part. Usually, certain chemicals are used to scratch the prepared samples to show the substructure, which is then looked at under a microscope. This study can show problems like bad heat treatment, flaws in the material, or sudden changes in phase that could have caused the part to break.

Utilizing Scanning Electron Microscopy (SEM)

SEM, or scanning electron microscopy, is a high-tech analysis method that creates detailed pictures of the surface texture of a subject. SEM is a great way to look at crack surfaces, wear patterns, and the makeup of materials when figuring out why car automotic parts fail. With SEM, scientists can see things that they can't see with visual microscope because of its high magnification and depth of field. When you use SEM to look at car parts, you can find specific fracture patterns, like wear striations or cleavage facets, that can tell you a lot about how the part failed. A lot of SEMs also have Energy Dispersive X-ray Spectroscopy (EDS) features that let you look at certain parts of the sample's surface and see what elements they contain.

Performing Chemical Composition Analysis

The car parts should have a chemical composition study done to see if they meet the standards for the materials and to find out if there were any problems with the composition that caused them to fail. A few tools that can be used for this are X-ray Fluorescence (XRF), Optical Emission Spectroscopy (OES), and Mass Spectrometry. It is important to pick the right way to study car parts based on what you need to learn and how accurate you need to be. You can find problems with these methods, such as bad alloying, contamination, or the presence of harmful impurities that could have made the part work less well. Another thing that chemical makeup analysis can do is make sure that the part was made from the right material. This is important to do to make sure that the part is strong and reliable.

Conclusion

Failure study of car automotic parts is a difficult but important task in the auto business. Engineers and analysts can find out why parts fail by using a methodical process that includes collecting data, eye inspection, non-destructive testing, and damaging analysis. This thorough method not only helps make products safer and better, but it also leads to new ideas in designing and making cars. In the future, as technology keeps getting better, new analysis tools and methods will help us understand and stop automobile part breakdowns. This will make the cars on our roads safer and more reliable.

At Alwin Asia Limited, we understand the importance of high-quality automotive parts and rigorous failure analysis. Our partner company, Dongguan Yongsheng Hardware Plastic Product Co., Ltd., has over 20 years of experience in plastic mould, die casting mould, and plastic product manufacturing. With our ISO9001:2015 certification and commitment to quality, we provide comprehensive OEM services, including design, development, mold fabrication, production, and secondary processing. Our convenient location near Shenzhen Airports makes it easy for international clients to visit our facility. For more information about our services or to discuss your automotive parts needs, please contact us at sales-c@alwinasia.com.

FAQ

Q: What is the primary goal of automotive parts failure analysis?

A: The primary goal is to identify the root causes of component failures to improve product quality, enhance vehicle safety, and prevent future failures.

Q: Why is visual inspection important in failure analysis?

A: Visual inspection helps identify obvious signs of failure, such as cracks, deformation, or unusual wear patterns, which guide further investigation.

Q: What are some non-destructive testing methods used in automotive parts analysis?

A: Common non-destructive methods include X-ray and CT scanning, magnetic particle inspection, and dye penetrant testing.

Q: How does Scanning Electron Microscopy (SEM) contribute to failure analysis?

A: SEM provides high-resolution images of surface topography, allowing analysts to examine fracture surfaces, wear patterns, and material composition in detail.

Q: Why is chemical composition analysis important in automotive parts failure analysis?

A: Chemical analysis helps determine if the part meets material specifications and can reveal issues like improper alloying or contamination that may have contributed to the failure.
